Chipset
North Bridge: Intel C202

Memory
Number of DDR3 Slot: 4 x 240Pin
DDR3 Standard: DDR3 ECC UDIMM
Maximum Memory Supported: 32GB
ECC Supported: Only

Expansion Slots
PCI Express x8: 6 x SATA 3.0 Gb/s
SATA RAID: 0/1/5/10

Onboard Video
Onboard Video Chipset: Nuvoton WPCM150GA0BX

Onboard LAN
LAN Chipset: Intel 82579LM
LAN Speed: 10/100/1000Mbps
Second LAN Chipset: Intel 82574L
Second LAN Speed: 10/100/1000Mbps
Max LAN Speed: Dual 10/100/1000Mbps

Rear Panel Ports
PS/2: Yes x2
COM: Yes x1
Video Ports: D-Sub
USB 1.1/2.0: 2 x USB 2.0

Form Factor
Micro ATX

Item Dimension (L"xW"xH")
10 x 10 x 3

Weight
2.50 lb

Warranty Information
1 Year
