| Vehicle | License plate image enhancement |
| Traffic flow statistics | Motor vehicle/Non-motorized vehicle/Pedestrian |
| Behavior analysis | Fast movement/Tripwire crossing/Intrusion/Area entry or exit/Loitering |
| Crowd flow analysis | Queue length/Head counting/Crowd flow statistics |
| Target | Target detection/Target enhancement/Target attribute recognition/Target recognition |
| Person | Person detection/Personal attribute recognition |
| Non-motorized vehicle | Object classification/Cyclist attributes |
| CPU | Hi3516DV300 |
| Computing power | 1 TOPS |
| Memory | DDR3 1.0 GB |
| Flash type | SPI NAND FLASH |
| Max resolution | 4MP 2560(H)*1440(V) |
| Sensor size | 1/1.8" CMOS |
| Min illumination | Color: 0.005 lux (F1.2, AGC ON, 1/30s shutter speed); B/W: 0.0025 lux (F1.2, AGC ON, 1/30s shutter speed) |
| Focal length | 2.8-12mm |
| Angle of view | W:102°(Horizontal)*52.0°(Vertical) T:39°(Horizontal)*22°(Vertical) |
| Illumination distance | 15m |
| Video encoding format | MJPEG/H.264/H.265 |
| Video frame rate | Configurable (25 fps or 30 fps) |
| Audio encoding format | G.711a/G.711u/G.726/OPUS |
| 1 + N | Supported |
| RS-485 port | Supported |
| Boolean port | Supported |
| Ethernet port | Supported |
| Ethernet port quantity | 1 |
| Ethernet port bandwidth | One RJ45 10M/100M adaptive Ethernet port |
| Power type | DC12V,PoE(IEEE 802.3at) |
| Power consumption | Maximum:11.4W,typical:3.6W |
| Operating temperature | –30°C to +55°C (illuminator disabled) –30°C to +40°C (illuminator enabled) |
| Operating humidity | 5% to 95%(non-condensing) |
| IP rating | IP67 |
| IK rating | IK10 (except for the viewing window) |
