802.11a/b/g/n/ac/ac Wave 2, 2 x 2:2, 1.267 Gbit/s
| Specifications | AP5510-W-GP |
| Dimensions (H x W x D) | 38.5 mm x 150 mm x 86 mm |
| Power Input | DC: 12 V ± 5% |
| Maximum Power Consumption | 14.2 W Note: The actual maximum power consumption depends on local laws and regulations. |
| Interface Type | Uplink: 1 x GPON Downlink: 4 x GE |
| Operating Temperature | 0°C to 40°C |
| Antenna Type | Built-in smart antennas |
| Maximum Number of Users | ≤ 256 |
| Maximum Transmit Power | 2.4G: 23 dBm (combined power) 5G: 23 dBm (combined power) Notes: The actual transmit power depends on local laws and regulations. |
| MIMO: Spatial Streams | 2 x 2:2 |
| Radio Protocols | 802.11a/b/g/n/ac/ac Wave 2 |
| Maximum Rate | 1.267 Gbit/s |
